60V 25A E-Forklift Battery Charger
Color Option: Silver / Black
Output power series: 1800W
Applied to battery types: 60V Lead-acid, AGM, GEL
Applied to EV types: E-forklifts, E-cars, electric AGV carts
Charging method: Pre-charge, CC, CV and Floating or Automatic Cut-off
Size: 330 x 150 x 90 mm
Input 110Vac or 230Vac
Max 73.5V 25Amps smart charging
- Product Details
60V 25A E-Forklift Battery Charger
Brief Description:
60V 25Amps intelligent battery charger is designed for lithium or lead acid battery, input with single 110 or 230Vac and rated output voltatge is 60 Volt 25 amps. Smart max charging voltage is 73.5V for lead acid type batteries and 73V for Lithium batteries. Intelligent 4 steps charging with pre-charge, CC, CV and floating or automatic cut-off, this charger will charge your batteries with very fast speed, with high efficiency and protect your battery life to the max. Aluminum housing, light weight and portable.
Features:
Advanced high frequency switching mode power supply technology.
DC output isolated from AC input.
Input 110V or 230Vac, 50Hz~60Hz.
Charging parameters are insensitive to the AC input line voltage variations.
Completely automatic battery charging: Pre-charging, CC, CV, Absorption, Float or Cut-off.
2 LEDs: LED1 Red (power on), LED2 Red / green (charging/full)..
Possibility to customize charging curve for request.
Protections: Short circuit, Over-voltage, Over-temperature, Reverse Polarity.
Efficiency > 90%.
Forced ventilation with fans.
100% full load burn-in test.
Aluminum casing, light weight, portable.
Technical Specs.:
1) Dimensions(LxWxH): 330 x 150 x 90 mm
2) Net weight: 5.5 KG
3) Max charging voltage(CV): 73.5 volts
4) Floating voltage: 69Vdc
5) Max output current (CC): 25 amps
6) Charging method: Pre-charge, CC, CV, floating / trickle or shut off
7) AC input voltage: 110V or 230Vac
8) AC input freq.: 50 / 60 Hz
9) AC plug: custom-made
10) Output connector type: customized by applications
11) Enclosure: Aluminum
