48V 8A CAN Battery Charger

48V 8A Smart Battery Charger with CAN Bus Communication

Descriptions:

CAN battery charger 48V 8A, designed for 48V lithium ion battery powered Electric Motorcycles. Input with PFC worldwide 110 to 230Vac and rated output voltatge is 48V 8A. Smart max charging voltage is 54.6 / 58.4V for li-ion type batteries. Intelligent 4 steps charging with pre - charge, CC, CV and floating or automatic cut-off, this charger will charge your E-motorcycles / E-Scooters battery very fast, with high efficiency and protect your battery life to the maximum. High quality, factory price and 2 years warranty. As original battery chargers supplier / manufacturer / factory, Danl provide full charging solution for your EV products.

Specifications:

AC input voltage: 90 to 264Vac

AC input freq.: 50 / 60 Hz

Rated output: 48V 8Amps

Max charging voltage: 54.6V / 58.4V

Communication port: CAN

Dimensions(LxWxH): 230 x 120 x 70 mm

Net weight: 2.5 KG

Housing: Aluminum

Color: silver or black

Techonolgy:

High Frequency Switching Mode Power Supply

Smart MCU contolled

Protections:

Short circuit, Over-voltage, Over-temperature, Reverse Polarity.

Warranty:

Fully 2-year warranty with Free Replacing Policy.

Resposing in 24 hours after getting failed product report from customers.

Applications:

Charging 48V Lithium Battery Powerd Electric Motorcycles / Scooters.

Special Function For EV:

1) In-lock signal is available: EV can't start when charging.

2) Remote signal wire is available for connecting control digital display board.

Charging method:

For Lead-acid Battery: pre-charge, CC, CV, floating.

For Lithium Battery: pre-charge, CC, CV, auto cut-off.

Input Plug & Output Connector:

We supply different plugs and connecotor by customer's applications.
