36V 25A Battery Charger
Item number: VL3625L
Dimensions: 260 x 150 x 90 mm
Net weight: 4.5 KG
Max charging voltage(CV): 44.1Vdc
Max output current (CC): 25 amps
Charging method: Automatic CC, CV, Floating
AC input voltage: 110V or 230V
AC input freq.: 50 / 60 Hz
Case material: Aluminum
- Product Details
36V 25A Lead-acid Battery Charger
Brief Description:
Designed for 36V lead acid battery, input with 110 or 230Vac and rated output voltatge is 24V 40A. Smart max charging voltage is 44.1 SLA/AGM/GEL batteries. Intelligent 4 steps charging with pre-charge, CC, CV and floating or automatic cut - off, this charger will charge your racing battery very fast, with high efficiency and protect your battery life to the max. High quality, factory price and 2 years warranty.
Features
1) Optional charging methods: Lithium or AGM batteries.
2) Advanced high frequency switching mode power supply technology.
3) DC output isolated from AC input.
4) Input 110/230Vac, 50Hz~60Hz.
5) Charging parameters are insensitive to the AC input line voltage variations.
6) Completely automatic 4 steps charge: pre-charge, CC, CV, floating/trickle or shut-off.
7) Protections: Short circuit, Over - voltage, Over - temperature, Reverse Polarity.
8) Aluminum casing, light weight, portable.
9) 100% full load burn-in test.
10) 2 years warranty.
Technical Specs.:
1) Dimensions(LxWxH): 260 x 150 x 90 mm
2) Net weight: 4.5 KG
3) Max charging voltage(CV): 44.1 volt
4) Floating voltage: 41.4V
5) Max output current (CC): 25 amps
6) Charging method: Automatic CC, CV, Floating
7) AC input voltage: 110 / 230Vac
8) AC input freq.: 50 / 60 Hz
9) AC plug: custom-made
10) Output connector type: customized by applications
11) Enclosure: Aluminum
| Output series: 1200W Size: 260×150×90 mm Net weight: 5.0 KG | ||||||
| Input | Model | Apply to battery types | Floating V | CV (V) | CC (A) | Switching |
|
AC Input: 110 / 230V
Frequency: 47~63HZ
|
VL1250L | 12V LiFePO4 Battery | 14.6V | 50A | CC5~8% | |
| VL1250 | 12V Lead-acid Battery | 13.5V | 14.7V | 50A | CC20% | |
| VL1450 | 14V AGM Battery | 13.5V | 14.4V | 50A | CC20% | |
| VL1650L | 16V LiFePO4 Battery | 18.2V | 50A | CC5~8% | ||
| VL2425LM | 24V Li-MnO2 Battery | 29.4V | 25A | CC5~8% | ||
| VL2425L | 24V LiFePO4 Battery | 29.2V | 25A | CC5~8% | ||
| VL2425 | 24V Lead-acid Battery | 27.6V | 29.4V | 25A | CC20% | |
| VL3618LM | 36V Li-MnO2 Battery | 42V | 18A | CC5~8% | ||
| VL3618L | 36V LiFePO4 Battery | 43.8V | 18A | CC5~8% | ||
| VL3618 | 36V Lead-acid Battery | 41.4V | 44.1V | 18A | CC20% | |
| VL4815LM | 48V Li-MnO2 Battery | 54.6V | 15A | CC5~8% | ||
| VL4815L | 48V LiFePO4 Battery | 43.8V | 15A | CC5~8% | ||
| VL4815 | 48V Lead-acid Battery | 55.2V | 58.8V | 15A | CC20% | |
| VL6012L | 60V LiFePO4 Battery | 73V | 12A | CC5~8% | ||
| VL6012 | 60V Lead-acid Battery | 67.5V | 73.5V | 12A | CC20% | |
| VL7210L | 72V LiFePO4 Battery | 87.6V | 10A | CC5~8% | ||
| VL7210 | 72V Lead-acid Battery | 81V | 88.2V | 10A | CC20% | |
| VL8408L | 84V LiFePO4 Battery | 102.2V | 8A | CC5~8% | ||
| VL8408 | 84V Lead-acid Battery | 94.5V | 102.9V | 8A | CC20% | |
|
Note: customized input / output / plug type / connectors are available. |
||||||
