24V 15A Waterproof Battery Charger

24V 15A Waterproof / Marine Battery Charger

Descriptions:

Waterproof / Marine battery charger 24V 15A, designed for 24V lithium ion battery powered Electric Motorcycles. Input with PFC worldwide 110 to 230Vac and rated output voltatge is 48V 8A. Smart max charging voltage is 28 / 29.2 / 29.4V for li-ion type batteries. Intelligent 4 steps charging with pre - charge, CC, CV and floating or automatic cut-off, this charger will charge your E-motorcycles / E-Scooters battery very fast, with high efficiency and protect your battery life to the maximum. High quality, factory price and 2 years warranty. As original battery chargers supplier / manufacturer / factory, Danl provide full charging solution for your EV products.

Specifications:

AC input voltage: 90 to 264Vac with PFC

AC input freq.: 50 / 60 Hz

Rated output: 24V 15Amps

Max charging voltage: 28 / 29.2 / 29.4V

Waterproof rate: IP65 / IP66

Dimensions(LxWxH): 230 x 135 x 70 mm

Net weight: 3.5 KG

Housing: Aluminum

Color: silver or black

Techonolgy:

High Frequency Switching Mode Power Supply

Smart MCU contolled

Protections:

Short circuit, Over-voltage, Over-temperature, Reverse Polarity.

Warranty:

Fully 2-year warranty with Free Replacing Policy.

Resposing in 24 hours after getting failed product report from customers.

Applications:

Charging 36V Lithium Battery Powerd Electric Motorcycles / Scooters.

Special Function For EV:

1) In-lock signal is available: EV can't start when charging.

2) Remote signal wire is available for connecting control digital display board.

Charging method:

For Lead-acid Battery: pre-charge, CC, CV, floating.

For Lithium Battery: pre-charge, CC, CV, auto cut-off.

Input Plug & Output Connector:

We supply different plugs and connecotor by customer's applications.
