24V 10A Waterproof Battery Charger

24V 10A Waterproof / Marine Lithium Battery Charger

Brief Descriptions:

Waterpoof / Marine Battery Charger 24V 10A with IP65 / IP66 rate waterproof, is designed for lithium-ion, LiFePO4 battery powered electric vehicles or marine appliecation, input with PFC worldwide 90~264Vac and rated output voltatge is 24V 10A. Smart max charging voltage is 28.8V / 29.2V / 29.4V for Li-ion / LiFePO4 batteries. MCU coutrolled and intelligent 4 steps charging with pre-charge, CC, CV and floating or automatic cut-off, this charger will charge your electric motorcycless very fast, with high efficiency.

Features:

Advanced high frequency switching mode power supply technology.

DC output isolated from AC input.

Auto worldwide Input 110-230Vac (90~264Vac) with PFC, 50Hz ~ 60Hz.

Charging parameters are insensitive to the AC input line voltage variations.

Completely automatic battery charging: Pre - charging, CC, CV, Absorption, Float or Cut - off.

2 LEDs: LED1 Red (power on), LED2 Red/green (charging/full)..

Possibility to customize charging curve for request.

Protections: Short circuit, Over-voltage, Over-temperature, Reverse Polarity.

Efficiency > 92%.

Forced ventilation with fans.

100% full load burn-in test.

Aluminum casing, light weight, portable, on-board.

Technical Specs.:

1) Dimensions(LxWxH): 220 × 93 × 49 MM

2) Net weight: 1.5 KG

3) Max charging voltage(CV): 28.8 / 29.2 / 29.4 volt

4) Floating voltage: /

5) Max output current (CC): 15 amps

6) Charging method: automtaic Pre-charge, CC, CV, Floating

7) AC input voltage: 110-230 Vac universal

8) AC input freq.: 50 / 60 Hz

9) AC plug: US, AU, UK, Euro

10) Output connector type: Clips, Anderson

11) Enclosure: Aluminum

12) Waterproof rate: IP65 / IP66
